Introduction of rotary wrecker towing truck:
The rotator wrecker towing truck is also called rotator tow truck, recovery truck, rotator wrecker truck, road wrecker truck, etc.
Rotator wrecker truck consists of the chassis, hoisting equipment,truck tow hook, double tow truck winch, tow truck wheel lift, hydraulic system, electric control system, truck body and the tool boxes.
Product Futures:
The wrecker truck can hoist, lift, draw and be with other special functions, mainly
used in highway, garage and city road obstacle cleaning. The heavy duty rotator wrecker towing truck can be used to tow the heavy duty dump truck, large concrete mixer truck and other heavy-duty trucks at moutain side or suburbs.
As a professional rotator towing truck supplier, our rotator wrecker towing trucks can meet all your demand. Right hand drive rotator wrecker towing trucks, left hand drive rotator wrecker towing trucks, etc. In wrecker truck types, we produce flatbed tow truck, under lift wrecker truck, wrecker towing truck with crane,etc.
Advantages:
1. 360° full rotated crane boom with reliable quality.
2. Key parts and large stressed parts are made of high strength HG70 steel, long service time.
3. Adpot Italy imported special balance valve.
4. Operation on both sides of the truck and remote is available, easy and convenient operation.
Items | Descriptions | Specifications and Types |
General | Truck Name | RHD 45ton Wrecker Tow Truck |
Drive Type | 8*4 | |
Gross Vehicle Weight(kg) | 31000 | |
Curb Weight (kg) | 22400 | |
Overall Dimensions L*W*H(mm) | 11380×2550×3900 | |
Engine | Engine Brand | Weichai |
Fuel Type | Diesel | |
Power | 430HP/316KW | |
Emission Standard | Euro III | |
Displacement | 11596cc | |
Engine Type | 6 cylinders in line, water cooling, turbo-charged diesel engine, inter-cooling | |
Chassis | Chassis Brand | Shacman |
Tire No. | 12+1 | |
Tire Specification | 12.00R20 | |
Wheelbase (mm) | 1800+4575+1400 | |
Axle No. | 4 | |
Steering Wheel | Left hand drive or right hand drive with power-assisted | |
Gear Box | Fast 12 speed forward with 2 reverse, manual | |
Brake | Air brake | |
Cab | Flat cab, one row with single sleeper, with air conditional | |
Lifting and Towing | No. Of winch (PCS) | 2 |
Per Winch Capacity(kg) | 25000 | |
Under Lift Capacity(kg) | 45000 | |
Steel wire length(m) | 45 | |
Boom rotate angle | 360 degree | |
Operation Type | Manual and Remote control |
