| Quantity: | |
|---|---|
Discription:
The Road washing truck is composed by chassis, auxiliary engine, air blower, magnetic valve, sweeping system, suction system, water sprinkling system, hydraulic system, etc.
Advantages
1:Efficient cleaning, saving labor costs, improving cleaning quality, etc.
2:Environmental benefits Describe the contribution of cleaning vehicles in reducing environmental pollution, including reducing noise pollution, reducing energy consumption and improving cleaning efficiency.
Features:
1: ISUZ U Chassis and engine, powerful, reliable performance, no overhaul with 100,000 km.
2: Large cleaning width, low oil consumption, easy operation.
3: Dustbin and water tank are made of stainless steel.
4:The ISUZU road sweeper truck is designed and developed on the basis of the Dongfeng light truck special vehicle chassis to meet needs of sweeping and cleaning urban pavement and curb. The principle of pure suction under negative pressure is adopted to guarantee strong suction force, dust-free working, simple operation, and excellent performance. It can quickly and efficiently sweep the household garbage and spilled objects in streets and roads.
Technology:
Chinese Special Purpose Truck Manufacturer ISUZU Road Washing Truck | ||
Vehicle details | ||
GVW | 8,400 kg | |
Kerb Weight | 6,900kg | |
Overall dimension | 7200x2200x2800 (mmxmmxmm) | |
Cab | Cab capacity | 2 persons' seat with air condition |
Chassis | ||
Chassis brand | ISUZU | |
Drive Type | 4X2, Left hand drive or Right hank drive | |
Fuel Type | Diesel | |
Engine Make | ISUZU engine | |
Horse power | 190 HP (140kw) | |
Displacement | 5193 cc | |
Air conditioner | Equipped | |
Type of fuel | Diesel | |
Emission standard | Euro V | |
Transmission | 6-speed forward, 1-reverse | |
Brake | Air Brake | |
No. of axles | 2 | |
Tyre | 7.00R16/(6+1)pcs | |
Max speed | 105 km/h | |
Paint | Automotive metallic paint | |
Superstructure details | ||
Water Tank Capacity | 4000 Liters Carbon steel or Stainless Steel | |
Dustbin tank capacity | 3 cbm, Stainless steel | |
High Pressure Pump | Imported Germany high pressure waterpump122L/min @16Mpa | |
Sweeping Speed | 3-20 km/h | |
Max Sweeping Width | 3.5 m | |
Brooms | 2 sets at each side,at diameter 900 m | |
Auxiliary Engine | Cummins engine 160HP(118KW),Superpowerful | |
Optional | Backup alarm, Camera, Stainless steel | |
