Description:
ISUZU Brand 4 Tons Tow Wrecker are often designed with a combination of versatility and high efficiency. They are equipped with hydraulic systems, winch equipment, support legs, etc. These configurations allow wreckers to easily tow, lift, and transfer all types of vehicles.
In addition, some high-end wreckers are also equipped with advanced electronic control systems, which further ensure the efficiency and safety of the operation through accurate operation.
Specification:
Technical Specification | |
Vehicle | Tow Wrecker for exporting |
Overall dimension (mm) | 7470 × 2350 × 2440 |
Flatbed dimension (mm) | 5550 × 2300 |
Gross Vehicle Weight (kg) | Appro × 8675 |
Net weight (kg) | Appro × 4480 |
Loading (kg) | / |
Wheel base (mm) | 3815 |
Max speed (km/h) | 110 |
Truck Chassis Parameter | |
Manufacturing year | 2021 |
Cabin | Single row cabin,power steering, ABS, air conditioner, cabin roof warning light, 3 passengers,left hand drive |
Traction system | 4×2 |
Engine | Brand : ISUZU/DFAC/JAC/JMC.... |
Model : 4KH1CN5HS | |
Engine power : 130hp | |
Type : diesel, 4 cylinder, turbocharged, inter-cooled. | |
Displacement : 2999ml | |
Emission standard : Euro 5 | |
Transmission | 6 forward,1 reverse, manual operated |
Tire model | 7.00R16 |
No.of tires | 6pcs, and a spare tire |
Wrecker Body Parameter | |
Characteristic | (1) 4 ton hydraulic winch 1 set. |
(2) Rear towing arm assembly 1 set. | |
(3) Auxiliary wheel 2pcs. | |
(4) Steel wire rope 21m. | |
(5) Bundle rope 4pcs. | |
(6) Rear tail lights LED,both sides electronic lights. | |
(7) Tool box on both sides. | |
Performance | 1. Flatbed towing 4 ton, wheel lit 2.5 ton. |
2. Hydraulic control flatbed and carriage arm,with hydraulic operation lever. | |
3. Winch speed : 8m/min. | |
4. Flatbed minimum tilt angle: 10°. | |
5. Flatbed working stroke: 2680mm | |
