Truck Description:
Flatbed Tow Truck can meet the needs of public security traffic departments, specialized rescue companies, auto maintenance companies, etc., able to safely and quickly remove accident& fault and peccancy vehicles, so as to ensure that road is unblocked.
Key Words:
Flatbed Tow Truck (also called wrecker tow truck, mobile crane truck, knuckle boom crane, lorry loading crane, truck with crane) is type of equipment for lift cargo, load, transport and unload broke truck or motor truck.
Performance Features:
1: ISUZU chassis, ISUZU engine, super powerful, reliable performance.
2: The flat plat is formed by die stamping, with high strength and beautiful & elegant appearance.
3: The main components of the hydraulic system for road-block removal are the international famous brand.
4: The support arm is made through the bending and forming of high-strength steel plate. Adopting the automatic welding method, with few weld joints and high accuracy & strength, not easy to be deformed.
5: The main structural components adopt the fixture making method, to ensure the accuracy and product consistency.
Technology Parameters:
ISUZU Road Wrecker Truck | ||
Vehicle details | GVW | 10,000 kg |
Kerb Weight | 5,300 kg | |
Overall dimension | 8000x2350x2500 (mmxmmxmm) | |
Chassis | Cab capacity | 3 persons' seat with air condition |
Chassis brand | ISUZU | |
Drive Type | 4X2, left hand drive | |
Fuel Type | Diesel | |
Engine Make | ISUZU engine | |
Horse power | 190HP (140kw) | |
Displacement | 5193cc | |
Emission standard | Euro V | |
Transmission | 6-speed forward, 1-reverse | |
Brake | Air Brake | |
No. of axles | 2 | |
Tyre | 8.25-16/(6+1)pcs | |
Max speed | 90 km/h | |
Paint | Automotive metallic paint | |
Superstructure details | Towing Type | Slide bed with wheel - lift |
Flatbed Payload | 5 tons | |
Towing capacity | 4 tons | |
Hydraulic winch | One 40KN hydraulic winch with 25 m galvanized wire rope connect one hook | |
Remark：Above specification is just for reference, please send us your detail request. | ||
